Xtreme Clutch 230mm Sprung Organic Twin Plate Clutch Kit Nissan Z 3.0 with Flywheel KNI23561-2A
2 518 €
2 171 €
/ per
Tax included.
Not in stock, available to order
Product description
Xtreme Clutch 230 mm sprung organic twin-plate clutch kit for the Nissan Z 3.0 twin-turbo manual. Includes a matching single-mass conversion flywheel.
FITMENT Nissan Z 3.0 twin turbo, from May 2022; VR30DDTT, 2997 cc petrol, 298 kW. Manual-transmission application only.
SPECIFICATIONS Part number: KNI23561-2A Construction: twin plate Friction discs: sprung organic Disc diameter: 230 mm Input spline: 24 teeth, 25.4 mm diameter Supplier-rated torque capacity: 1000 Nm Flywheel step: +3.8 mm Included flywheel: single-mass conversion Recommended use: high-power street applications
PURCHASED PARTS PACKAGE Twin-plate clutch assembly with two sprung organic friction discs, matching flywheel, release bearing, flywheel bolts, pressure-plate bolts, pilot bush and alignment tool. The supplied components are shown in the product photograph.
INSTALLATION AND USE Match the engine code, gearbox input spline, flywheel and release system before ordering. Follow the supplied installation and bedding-in instructions. Single-mass conversion can increase transmitted engine harmonics or gearbox rattle. The supplier torque rating does not establish a safe limit for other drivetrain components. Xtreme Clutch Nissan Z upgrade guide.
