Tein STREET BASIS Z Coilover Suspension Toyota Mark X (GRX120) GSQ22-81SS2

GSQ22-81SS2

FITMENT
Lexus Is F (USE20) 2007–2014
Lexus IS250 (GSE20) 2005–2013
Lexus IS250 (GSE20R) 2006–2013
Lexus IS350 (GSE21) 2005–2013
Toyota Mark X (GRX120) 2004–2009
Toyota Mark X (GRX121) 2004–2009
Toyota Mark X (GRX130) 2009–2013
Toyota Mark X (GRX133) 2009–2013
Toyota Mark X G'S (GRX130) 2012–2013
Toyota Reiz (GRX122L) 2004–2009

PRODUCT INFORMATION
Twin-tube construction
Fixed damping
Spring-seat ride-height adjustment
Designed for use with OE upper mounts

SPECIFICATIONS
Front spring rate: 7 kgf/mm (69 N/mm)
Rear spring rate: 7 kgf/mm (69 N/mm)

APPLICATION NOTES
Data applies to low down model(approx -15 mm).
Not tested on vehicle manufactured after dec 2013.
