Tein STREET BASIS Z Coilover Suspension Honda S660 (JW5) GSHG8-81SS2

GSHG8-81SS2

FITMENT
Honda S660 (JW5) 2015–2022

PRODUCT INFORMATION
Twin-tube construction
Fixed damping
Spring-seat ride-height adjustment
Designed for use with OE upper mounts

SPECIFICATIONS
Front spring rate: 2.5 kgf/mm (25 N/mm)
Rear spring rate: 3.3 kgf/mm (32 N/mm)
Standard ride-height change: front -15 mm / rear -15 mm
Recommended ride-height range: front -5 to -25 mm / rear -5 to -25 mm

APPLICATION NOTES
For vehicles with fog lights, if the position of the fog light is less than 250 mm from the ground, it may not comply with japan's vehicle safety regulations.
Please adjust ride height so the distance is over 250 mm.
