Tein Street Advance Z4 Lift Kit Suzuki Jimny (JB64W) VSUC2-G1BS2

VSUC2-G1BS2

FITMENT
Suzuki Jimny (JB64W) 2018–
Suzuki Jimny Sierra (JB74W) 2018–

PRODUCT INFORMATION
Lift-oriented suspension kit
Spring-seat ride-height adjustment
Adjustable damping

SPECIFICATIONS
Front spring rate: 2.3 kgf/mm (23 N/mm)
Rear spring rate: 2.4 kgf/mm (24 N/mm)
Standard ride-height change: front 25 mm / rear 20 mm
Recommended ride-height range: front 25 to 5 mm / rear 20 to 5 mm

APPLICATION NOTES
2-level ride height adjustment with the use of spacer.
Front: when tightening, be sure to apply the appropriate torque as specified in the included manual.
Over-torquing might lead to piston rod damage/breakage.
Rear: right and left springs differ.
Be sure to install on the correct side.
