Tein Street Advance Z4 Lift Kit Suzuki Jimny (JB23W) VSUC0-G1BS2

VSUC0-G1BS2

FITMENT
Suzuki Jimny (JB23W) 1998–2018

PRODUCT INFORMATION
Lift-oriented suspension kit
Spring-seat ride-height adjustment
Adjustable damping

SPECIFICATIONS
Front spring rate: 1.9 kgf/mm (19 N/mm)
Rear spring rate: 2.4 kgf/mm (24 N/mm)
Standard ride-height change: front 25 mm / rear 20 mm
Recommended ride-height range: front 25 to 15 mm / rear 20 to 10 mm

APPLICATION NOTES
2-level ride height adjustment with the use of spacer.
Rear: right and left springs differ.
Be sure to install on the correct side.
