PRODUCT INFORMATION Twin-tube construction 16-level damping adjustment Spring-seat ride-height adjustment Designed for use with OE upper mounts
SPECIFICATIONS Front spring rate: 7 kgf/mm (69 N/mm) Rear spring rate: 5.8 kgf/mm (57 N/mm)
APPLICATION NOTES Data applies to vehicle with vin 115927 or earlier. For vin 115928 or later, the same height can be achieved by lowering front spring seat by 5 mm. Data applies to vehicle with vin 120209 or earlier. For vin 120210 or later, the same height can be achieved by lowering front spring seat by 5 mm.
