PRODUCT INFORMATION Twin-tube construction 16-level damping adjustment Spring-seat ride-height adjustment Designed for use with OE upper mounts
SPECIFICATIONS Front spring rate: 5 kgf/mm (49 N/mm) Rear spring rate: 5 kgf/mm (49 N/mm) Standard ride-height change: front -35 mm / rear -35 mm Recommended ride-height range: front -25 to -45 mm / rear -25 to -45 mm
EDFC COMPATIBILITY Compatible EDFC motor kit: EDK05-12120 EDFC controller and any required accessories are sold separately
APPLICATION NOTES Front: exclusively for vehicle with 50.2 mm diameter OE strut. Not compatible with vehicles produced in china. Front: OE dust boot and bump rubber need to be modified. Rear: use of EDFC series is recommended, as it's difficult to adjust damping force by hand due to vehicle structure. Front: right and left springs differ. Be sure to install on the correct side.
