Tein MONO RACING Coilover Suspension Toyota Gr Yaris (GXPA16) VSTN0-K1NS4

VSTN0-K1NS4

FITMENT
Toyota Gr Yaris (GXPA16) 2020–2024

PRODUCT INFORMATION
Monotube construction
Track-focused setup
16-level damping adjustment
Full-length ride-height adjustment
Rebuildable

SPECIFICATIONS
Front spring rate: 14 kgf/mm (137 N/mm)
Rear spring rate: 12 kgf/mm (118 N/mm)
Standard ride-height change: front -30 mm / rear -25 mm
Recommended ride-height range: front -20 to -40 mm / rear -15 to -35 mm

APPLICATION NOTES
Front: camber-adjustable lower bracket, with 2 sets of adjustment collars (type-d) of different offsets included.
Front springs : selected from 12, 14, 16 kgf/mm.
Rear springs : selected from 10, 12, 14 kgf/mm.
US and UK spec included front: 14 kgf/mm / rear: 12 kgf/mm.
Optional springs- front: 12, 16 kgf/mm / rear: 10, 14 kgf/mm.
Price includes springs.
