Tein FLEX Z Coilover Suspension Toyota Corolla Hatchback (MZEA12L) VSTJ0-CUAA3

VSTJ0-CUAA3

FITMENT
Toyota Corolla (MZEA12L) 2019–
Toyota Corolla Hatchback (MZEA12L) 2019–
Toyota Corolla Hybrid 2019–

PRODUCT INFORMATION
Twin-tube construction
16-level damping adjustment
Full-length ride-height adjustment
Upper mounts included where specified for the application

SPECIFICATIONS
Front spring rate: 6 kgf/mm (59 N/mm)
Rear spring rate: 5.2 kgf/mm (51 N/mm)

EDFC COMPATIBILITY
Compatible EDFC motor kit: EDK05-12120
EDFC controller and any required accessories are sold separately

APPLICATION NOTES
Excluding 2023+ le trim (torsion beam rear suspension; gas engine only) model.
Front: use of EDFC series is recommended.
Cowl cover and top panel must be removed and/or modified in order to adjust damping force manually.
Rear: use of EDFC series is recommended.
(front & rear : damping force difficult to adjust manually).
