Tein FLEX Z Coilover Suspension Honda Integra Type R (DC5) VSA02-C1SA1

VSA02-C1SA1

FITMENT
Acura RSX (DC5) 2002–2006
Honda Integra (DC5) 2001–2006
Honda Integra Type R (DC5) 2001–2006

PRODUCT INFORMATION
Twin-tube construction
16-level damping adjustment
Full-length ride-height adjustment
Upper mounts included where specified for the application

SPECIFICATIONS
Front spring rate: 8 kgf/mm (78 N/mm)
Rear spring rate: 10 kgf/mm (98 N/mm)

EDFC COMPATIBILITY
Compatible EDFC motor kit: EDK05-12140
EDFC controller and any required accessories are sold separately

APPLICATION NOTES
Because the adjustable range of the camber angle is limited due to the vehicle characteristics, adjust the angle within the appropriate adjustable range of the toe angle.
Front: lh has left-hand threads.
Be sure to tighten in the correct (anticlockwise) direction.
(spring seat and lock).
