Tein FLEX Z Coilover Suspension Honda Integra (DC2) VSH48-CUSA1

VSH48-CUSA1

FITMENT
Acura Integra (DC2) 1997–2001

PRODUCT INFORMATION
Twin-tube construction
16-level damping adjustment
Full-length ride-height adjustment
Upper mounts included where specified for the application

SPECIFICATIONS
Front spring rate: 10 kgf/mm (98 N/mm)
Rear spring rate: 7 kgf/mm (69 N/mm)
Standard ride-height change: front -45 mm / rear -50 mm
Recommended ride-height range: front -35 to -55 mm / rear -40 to -60 mm

EDFC COMPATIBILITY
Compatible EDFC motor kit: EDK05-12120
EDFC controller and any required accessories are sold separately

APPLICATION NOTES
Front: reuse the brake line bracket from OE shock absorber.
Rear: bottom eye mt.
