Öhlins Road & Track Coilover Suspension Toyota Supra A90 TOS MU00S1

TOS MU00S1

FITMENT
BMW Z4 (G29) 2018-2022
Toyota Supra A90 (J29) 2019-

GENERAL INFORMATION
DFV technology (Dual Flow Valve)
Individual height adjustment
Rebuildable
Corrosion salt spray tested (ISO 9227)
2 year warranty

FRONT FEATURES
McPherson strut, upside down
Compression and rebound damping with one adjuster
Spring preload adjuster
Separate ride height adjustment
Approx. 20 mm lower than standard with recommended setup
Spring rate 90 N/mm
Use with original top mounts

REAR FEATURES
Conventional shock absorber
Compression and rebound damping with one adjuster
Spring preload adjuster
Separate ride height adjustment
Approx. 20 mm lower than standard with recommended setup
Spring rate 160 N/mm
Use with original top mounts

PURCHASED PARTS PACKAGE
Coil over kit incl. springs
C-Spanner (for spring preload adjustment)
Owners manual and mounting instruction

ADDITIONAL OPTIONS
Optional Millway adjustable top mounts G90530-GJ29 (not included)
Öhlins EDC Cancellation Kit 35020-30 (not included) for cars with Adaptive Variable Suspension
