The iconic Triple-R 1000, a firm favourite amongst the heavy truck and LCV sectors, is now offered with integrated amber flashing beacon function. Incorporating 16 different forward-facing flash patterns, the additional safety functionality within the lamp, combines with the possibility to connect a white or amber position/side light function, as well as the exceptional high beam driving light function to really set the Triple-R 1000 apart from the competition.
The Triple-R 1000 is a high-performance driving light that delivers a spot beam pattern well suited to road use. Recent styling updates to the Triple-R range have resulted in a clean contemporary design, with a more aggressive edge, to match the aesthetic design prevalent on modern vehicles. Boasting 9,240 lumen, and delivering 1 lux to 612m (E-Boost mode), the auxiliary LED driving light provides improved left/right spread of light without compromising the up/down spread which ensures suitability of the lights to a wide array of vehicles, including where the lights are mounted high on the vehicle. Dual-output ‘E-Boost’ technology allows for operation within ECE Regulation 112 parameters, when the supplied E-Boost cap is removed, and where country regulations demand for on-road use in parallel with your vehicle’s standard high beam driving lights.
SPECIFICATIONS Based on: 1 × Triple-R 1000 with Beacon.
Boost mode
Low-output mode
Voltage range (DC)
10-32V
10-32V
LED life
50,000 hours
50,000 hours
Weight
1.7 kg
1.7 kg
High beam function
Total luminous flux
9240 lm
1848 lm
Total driver 'FOV' flux †
5572 lm
1114 lm
Colour temperature
5000K
5000K
Number of high-output LEDs
8
8
Power consumption
88 W
17.6 W
Current draw (at 14.4V)
6.1 A
1.2 A
Certification
IP rating
IP68
IP68
Work Lamp
ECE R10
ECE R10
High beam
N/A
ECE R112
E-mark ref
N/A
12.5
Position light (white)
ECE R7
ECE R7
Beacon (Amber)
ECE R65
ECE R65
OPERATING CONDITIONS
Salt spray test
ISO 9227 (2000H)
ISO 9227 (2000H)
Vibration (BS EN 60068)
10Hz > 1000Hz, 0.14>20 (m/s²)²/Hz
10Hz > 1000Hz, 0.14>20 (m/s²)²/Hz
Operating Temperature
-40oC … +90oC
-40oC … +90oC
Photometric data
Horizontal beam angle
19 °
19 °
0.25 lx line
1225 m
548 m
0.5 lx line
866 m
387 m
1 lx line
612 m
274 m
3 lx line
354 m
158 m
WHAT'S INCLUDED
1 × Triple-R 1000 LED Lamp with Beacon Function
2 × Centre Mount (1114K)
Installation instructions
Road approval: Yes (12,5)
*Lamp uses E-BOOST technology. It is approved for road use (E-mark on the lens), but includes an off-road 'dual-output' function which increases intensity of light for when the vehicle is off-road.
