Part no. 0008-EVO-B
The ST / T Evolution range of products feature highly efficient, premium ‘bin’ 11W LEDs in combination with vacuum-metallised conical optics to deliver a powerful beam pattern with wide spread. This makes the products especially well-suited to rural and off-road applications. Incorporating the same electrical and product design across both ST and T lights, the former indicates lights that are UNECE certified to Regulation 112 as high beam driving lights, while the latter indicating the larger light bars not certified and intended for off-road use only operated via an independent switch.
Available in sizes ranging from the 124mm (5”) ST2 to the 1164mm (46”) T28, these are LED light bars benefitting from huge versatility, having been adopted across a wide range of different applications and vehicle types, since the products were first launched in 2010. Since then, the range has been re-engineered and re-designed incorporating the latest and best technology alongside a more contemporary, seamless, low profile design making them easier to install, more resistant to dirt, snow and ice accumulations and with styling guaranteed to complement and enhance the appearance of modern vehicles.
Specifications:
Based on: 1x ST8 Evolution.
| Voltage Range (DC) | 10-32V |
| LED Life | 50,000 hours |
| Weight | 1150 gr |
| HIGH BEAM FUNCTION | |
| Total Luminous Flux | 8272 Lm |
| Total Driver 'FOV' Flux † | 4980 Lm |
| Colour Temperature | 5000K |
| Number of High Output LEDs | 8 |
| Power Consumption | 95 Watts |
| Current Draw (at 14.4V) | 6.6 Amps |
| CERTIFICATION | |
| High Beam | ECE R112 |
| ECE Reference | 17.5 |
| DIMENSIONS | |
| Width | 364 mm |
| Depth | 68 mm |
| Height | 64 mm |
| PHOTOMETRIC DATA | |
| Horizontal Beam Angle | 40° |
| 0.25 lx Line | 786 metres |
| 0.5 lx Line | 555 metres |
| 1 lx Line | 393 metres |
| 3 lx Line | 227 metres |
Approved for road use: Yes (17,5) |
