The ST / T Evolution range of products feature highly efficient, premium ‘bin’ 11W LEDs in combination with vacuum-metallised conical optics to deliver a powerful beam pattern with wide spread. This makes the products especially well-suited to rural and off-road applications. Incorporating the same electrical and product design across both ST and T lights, the former indicates lights that are UNECE certified to Regulation 112 as high beam driving lights, while the latter indicating the larger light bars not certified and intended for off-road use only operated via an independent switch.
Available in sizes ranging from the 124mm (5”) ST2 to the 1164mm (46”) T28, these are LED light bars benefitting from huge versatility, having been adopted across a wide range of different applications and vehicle types, since the products were first launched in 2010. Since then, the range has been re-engineered and re-designed incorporating the latest and best technology alongside a more contemporary, seamless, low profile design making them easier to install, more resistant to dirt, snow and ice accumulations and with styling guaranteed to complement and enhance the appearance of modern vehicles.
SPECIFICATIONS Based on: 1 × ST6 Evolution.
Voltage range (DC)
10-32V
LED life
50,000 hours
Weight
912 g
High beam function
Total luminous flux
6204 lm
Total driver 'FOV' flux †
3735 lm
Colour temperature
5000K
Number of high-output LEDs
6
Power consumption
70 W
Current draw (at 14.4V)
4.9 A
Certification
High beam
ECE R112
ECE reference
10
Dimensions
Width
284 mm
Depth
68 mm
Height
64 mm
Photometric data
Horizontal beam angle
40°
0.25 lx line
680 m
0.5 lx line
481 m
1 lx line
340 m
3 lx line
196 m
WHAT'S INCLUDED
1 × ST6 Evolution LED Spotlight
1 × Centre Mount (1114K)
Installation instructions
