Part no. 0002-EVO-B
The ST / T Evolution range of products feature highly efficient, premium ‘bin’ 11W LEDs in combination with vacuum-metallised conical optics to deliver a powerful beam pattern with wide spread. This makes the products especially well-suited to rural and off-road applications. Incorporating the same electrical and product design across both ST and T lights, the former indicates lights that are UNECE certified to Regulation 112 as high beam driving lights, while the latter indicating the larger light bars not certified and intended for off-road use only operated via an independent switch.
Available in sizes ranging from the 124mm (5”) ST2 to the 1164mm (46”) T28, these are LED light bars benefitting from huge versatility, having been adopted across a wide range of different applications and vehicle types, since the products were first launched in 2010. Since then, the range has been re-engineered and re-designed incorporating the latest and best technology alongside a more contemporary, seamless, low profile design making them easier to install, more resistant to dirt, snow and ice accumulations and with styling guaranteed to complement and enhance the appearance of modern vehicles.
Specifications:
Based on 1x ST2 Evolution.
| Voltage Range (DC) | 10-32V |
| LED Life | 50,000 hours |
| Weight | 430 gr |
| HIGH BEAM FUNCTION | |
| Total Luminous Flux | 2068 Lm |
| Total Driver 'FOV' Flux † | 1245 Lm |
| Colour Temperature | 5000K |
| Number of High Output LEDs | 2 |
| Power Consumption | 23 Watts |
| Current Draw (at 14.4V) | 1.6 Amps |
| CERTIFICATION | |
| High Beam | ECE R112 |
| ECE Reference | 7.5 |
| DIMENSIONS | |
| Width | 124 mm |
| Depth | 68 mm |
| Height | 64 mm |
| PHOTOMETRIC DATA | |
| Horizontal Beam Angle | 40° |
| 0.25 lx Line | 393 metres |
| 0.5 lx Line | 278 metres |
| 1 lx Line | 196 metres |
| 3 lx Line | 113 metres |
Approved for road use: Yes (7.5) |
