Representing an evolution in our highest performance LED lighting solutions, the Elite+ range comprises products with enhanced performance, light distribution, and functionality. Improvements are in part made through the placement of supplemental yellow LEDs in each of the lights, which can either combine with the already superior white light high beam function for awe-inspiring night-time visibility at a slightly softer, more relaxing colour temperature. Or the option to operate the yellow LEDs on their own, with that light angled slightly down and to the sides of the road or track making this function ideal in snow, fog, or dust conditions.
The lights are intended to cycle through the different lighting modes via a momentary switch. The lighting modes are: Boost (white only), Combo (white + yellow), Snow/Fog/Dust Mode (yellow only), and E-mark (white only; road-legal at reduced output compliant with UNECE Reg 149). A memory function within the lamp means the previous mode selected will be in effect when your vehicle is restarted for example. Additionally, pressing and holding the momentary switch for 2 seconds will result in the light instantly jumping to the E-mark mode.
Despite the low-profile aero design of the Linear-6 Elite+, through advanced electronic design the light consists of an impressive 12 white LEDs and 6 yellow LEDs. With the light operating in Boost mode the white LEDs produce 5,100 raw lumen (25% more than the current Linear-6 Elite).
Based on: 1 × Linear-6 Elite+ LED Lamp.
SPECIFICATIONS
White LED's (Boost / Low Output Mode)
Yellow LED's (Fog / Dust / Snow Mode)
White & Yellow LED's (Combo Mode)
Voltage range (DC)
10-32V
10-32V
10-32V
LED life
50,000 hours
50,000 hours
50,000 hours
Weight
495 g
495 g
495 g
High beam function
Total luminous flux
5100 / 2500 lm
2,000 lm
7,100 lm
Total driver 'FOV' flux †
3645 / 1822 lm
1,200 lm
4,774 lm
Colour temperature
5000K
PC Yellow
N/A
Number of high-output LEDs
12
6
12 White / 6 Yellow
Power consumption
48 W / 24 W
21 W
69 W
Current Draw
3.6 A / 1.8 A
1.5 A
5.1 A
Peak current draw
4.9 A / 2.5 A
2 A
6.9 A
Certification
High beam
ECE R149
N/A
N/A
ECE reference
12.5 (Low Output Mode only)
WHAT'S INCLUDED
1 × Linear-6 Elite+ LED Lamp
1 × Anti-Theft Side Mount (1127K)
Installation instructions
Road approval: Yes (12.5) E-mark mode (white only )
