Representing the very best in slimline auxiliary high beam driving lights, the Linear range utilises a combination of highly efficient 3W LEDs and vacuum-metallised wide optics to deliver a perfectly tuned beam pattern for everyday road use. Measuring just 40mm in height, the Linear range is an excellent solution when either space is limited or when looking for a discreet installation that’s most likely to get noticed at night-time.
The Linear range is available in a variety of sizes from the 232mm (9”) Linear-6 to the 1282mm (51”) Linear-48. With the exception of the range topping Linear-48, all Linear products are fully UNECE certified to Regulation 112 as Class B Driving lights (for on-road use). Elite level products are also available across Linear-6/12/18 product lines with these products boasting twice the light output compared to the equivalent Standard version. The Linear-12 Elite and Linear-18 Elite lights are also available with the option for integrated position light function providing added safety and styling benefits.
SPECIFICATIONS
Voltage range: 10-32V
LED life: 50,000 h
Weight: 495 g
Total luminous flux: 4050 lm
Color temperature: 5000K
Number of high output LEDs: 12
Power consumption: 42 W
Current draw (at 14.4V): 2.9 A
WHAT'S INCLUDED
1 × Linear-6 Elite LED Lamp
1 × Anti-Theft Side Mount (1127K)
Installation instructions
