Part no. 0L42-EL-LNR
Representing the very best in slimline auxiliary high beam driving lights, the Linear range utilises a combination of highly efficient 3W LEDs and vacuum-metallised wide optics to deliver a perfectly tuned beam pattern for everyday road use. Measuring just 40mm in height, the Linear range is an excellent solution when either space is limited or when looking for a discreet installation that’s most likely to get noticed at night-time.
The Linear range is available in a variety of sizes from the 232mm (9”) Linear-6 to the 1282mm (51”) Linear-48. All Linear Standard grade products are fully UNECE certified to Regulation 112 as Class B Driving lights for on-road use (with the exception of: Linear-48, Linear-36 Elite, Linear-42 Elite and Linear-48 Elite). Elite level products are also available, with these products boasting at least twice the light output compared to the equivalent Standard version. The Linear-12 Elite and Linear-18 Elite lights are also available with the option for integrated position light function providing added safety and styling benefits.
Based on: 1x Linear-42 Elite.
| Voltage Range (DC) | 10-32V |
| LED Life | 50,000 hours |
| Weight | 3.5 kg |
| HIGH BEAM FUNCTION | |
| Total Luminous Flux | 33300 Lm |
| Total Driver 'FOV' Flux † | 23909 Lm |
| Colour Temperature | 5000K |
| Number of High Output LEDs | 84 |
| Power Consumption | 355 Watts |
| Current Draw (at 14.4V) | 24.7 Amps |
| CERTIFICATION | |
| High Beam | N/A |
| ECE Reference | N/A |
| DIMENSIONS | |
| Width | 1132 mm |
| Depth | 62 mm |
| Height | 40 mm |
| PHOTOMETRIC DATA | |
| Horizontal Beam Angle | 60° |
| 0.25 lx Line | 1530m |
| 0.5 lx Line | 1082m |
| 1 lx Line | 765m |
| 3 lx Line | 442m |
What's included
Approved for road use: No |
LAZER Linear-42 Elite
