Part no. 0L36-LNR
Representing the very best in slimline auxiliary high beam driving lights, the Linear range utilises a combination of highly efficient 3W LEDs and vacuum-metallised wide optics to deliver a perfectly tuned beam pattern for everyday road use. Measuring just 40mm in height, the Linear range is an excellent solution when either space is limited or when looking for a discreet installation that’s most likely to get noticed at night-time.
The Linear range is available in a variety of sizes from the 232mm (9”) Linear-6 to the 1282mm (51”) Linear-48. With the exception of the range topping Linear-48, all Linear products are fully UNECE certified to Regulation 112 as Class B Driving lights (for on-road use).
Based on: 1 × Linear-36 LED lightbar.
| Voltage range (DC) | 10-32V |
|---|---|
| LED life | 50,000 hours |
| Weight | 2.7 kg |
| High beam function | |
| Total luminous flux | 13500 lm |
| Total driver 'FOV' flux † | 9612 lm |
| Colour temperature | 5000K |
| Number of high-output LEDs | 36 |
| Power consumption | 126 W |
| Current draw (at 14.4V) | 8.8 A |
| Certification | |
| High beam | ECE R112 |
| ECE reference | 2 × 30 |
| Dimensions | |
| Width | 982 mm |
| Depth | 62 mm |
| Height | 40 mm |
| Photometric data | |
| Horizontal beam angle | 50° |
| 0.25 lx line | 940 m |
| 0.5 lx line | 665 m |
| 1 lx line | 470 m |
| 3 lx line | 271 m |
Road approval: Yes† (Ref 2x30)
† - Double E-Mark Approved (UN ECE Reg112/149)
