Part no. 0G18-EL-SM
Introducing Glide, the world’s first ‘formed’ LED light bar. Featuring a monocoque lens construction for highly weight-efficient inherent strength and robustness, Glide is a range of 20” curved light bars that deliver so much especially when considering their ultra low-profile design. The enviable balance of exceptional lighting performance and OE quality aesthetics, sympathetic to the front contours of a diverse number of vehicle types, makes, and models, make Glide an exceptional choice particularly within the passenger car and light commercial sectors.
Befitting any Lazer product with the ‘Elite’ tag, considering the lamp’s size the Glide Elite delivers the very highest levels of consistent light output in a carefully engineered beam distribution derived from a combination of Spot and Wide optics and LED arrangement. Those optics, vacuum-metallised in-house by Lazer to maximise reflectivity, harness the 12,800 raw lumens to deliver 1 lux to 624m while still maintaining a 66 degree horizontal spread of light. The ‘premium bin’ LEDs utilised within the Glide Elite lamps are carefully selected for their 80CRI, with this high colour rendering index providing more definition of colours and shapes for a clearer, safer night-driving experience.
In-built within each Glide lamp is a Dynamic Dip mode which provides a smooth transition between high and low output modes. The low output mode permits driving in compliance with UNECE Regulation 149 (Double E-Mark) where local laws require, and/or a reduced output which for example reduces glare from highly reflective surfaces such as large road signs. The Dynamic Dip function is activated after the light has been on for >2seconds by simply and quickly flashing the light off and on again.
Technical Specifications
BOOST |
LOW OUTPUT/ |
|
---|---|---|
Voltage Range (DC) | 10-32V | |
LED Life | 50,000 hours | |
Weight | 0.68 kg | |
HIGH BEAM FUNCTION | ||
Total Luminous Flux | 12,800 Lm | 3,840 Lm |
Total Driver 'FOV' Flux † | 8,012 Lm | 2,403 Lm |
Colour Temperature | 5000K | |
Power Consumption | 130 Watts | 38 Watts |
Peak Current Draw | 12.6 Amps | 2.7 Amps |
Current Draw (14.4V) | 9.2 Amps | 2 Amps |
Connector | 2-Pin/3-Pin Superseal (+25cm Cable) | |
DIMENSIONS | ||
Width | 517 mm | |
Depth | 71 mm | |
Height | 39 mm | |
CERTIFICATION | ||
IP Rating # | IP68 | |
High Beam (E9 approval) | ECE R149 (Double E-Mark) - Ref: 2x 12.5 (in Low Output Mode only) | |
EMC Certification | ECE R10 | |
Salt Spray Test | ISO 9227 | |
Dump Load Protection | ISO 7637-2 | |
PHOTOMETRIC DATA | ||
Horizontal / Vertical Beam Angle | 66° / 14° | |
0.25 lx Line | 1249m | 682m |
0.5 lx Line | 883m | 484m |
1 lx Line | 624m | 342m |
3 lx Line | 361m | 197m |
† - Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45° left/right, and +/- 10° up/down. For more information – click here.
# - All Lazer products are designed to meet the requirements of IP68 testing. Every lamp produced at Lazer UK facility is fully submerged under water prior to sending out.
Approved for road use: Yes |
