Tests voltage, start power and alternator performance
The MXS 5.0 TEST & CHARGE is suitable for use with batteries from 1.2Ah-110Ah. Its testing function gives you three easy to use programs to test battery voltage, start power and alternator performance to give you a complete picture of battery and vehicle charging system health. The MXS 5.0 TEST & CHARGE also includes a patented automatic desulphation program, a special Recond mode for reconditioning deeply discharged batteries and CTEK’s patented float/pulse system, which is the most efficient maintenance mode when a battery is connected for long periods.
FEATURES Charges batteries from 1.2Ah up to 110Ah Patented float/pulse maintenance phase Easy to read LED display Splash and dust proof (IP65) Safe spark free operation Reverse polarity protected Short circuit proof Fully automatic ‘connect and forget’ charging Easy to use battery and alternator testing function Charges batteries up to 110Ah Smaller battery, normal battery, cold weather and Recond programs
SPECIFICATIONS Charging category - AC charging Input - 220–240 VAC, 50–60 Hz, 1.1 A Output - 14.4/14.7/15.8 V, 5.0 A Battery chemistry - Lead acid Battery types - 12 V:, WET, MF, Ca/Ca, AGM, GEL Battery capacity - 1.2–110 Ah Back current drain*: Corresponding to less than 1 Ah/month Battery voltage - 12 V Ambient operating temperature - -20 ˚C to +50 ˚C (- 4 °F to +122 °F) Start voltage - 2.0 V Ripple**: Less than 4 % Degree of protection - IP65
