AP Racing Ventilated Brake Disc 356x28mm (CP3781-2126/2127)

AP Racing Ventilated Brake Disc 356x28mm (CP3781-2126/2127)

Outside diameter: 356.0 mm
Thickness: 28.0 mm
Mounting PCD: 228.6 mm
Mounting holes: 12
Fixing type: Bolted

Select the required side by exact complete part number.

Disc weights are reference values and can vary with the face machining. They exclude packaging.

Groove and drilling styles

CG12: 12 curved, backward-facing grooves per face.

AP Racing part numbers: CP3781-2126CG12 (right), CP3781-2127CG12 (left).

Check the part number and mounting dimensions against your application. See the AP Racing catalogue for full disc details.

For ordering assistance, email info@radaauto.ee.

The supplied left-hand CP3781-2127CG12 component row specifies 356 x 28 mm, 12 mounting positions on a 228.6 mm pitch circle and D54 pad depth. One replacement disc is supplied per ordered unit; mounting bells and fixing hardware are separate. Packed weight for this additional option is unconfirmed.
