AP Racing Ventilated Brake Disc 343x32mm (CP3581-564/565)
665 €
/ per
Tax included.
Not in stock, available to order
Product description
AP Racing Ventilated Brake Disc 343x32mm (CP3581-564/565)
Outside diameter: 343 mm
Thickness: 32 mm
Mounting PCD: 215.9 mm
Mounting holes: 12
Fixing type: Floating
Mounting bobbin: CP2494-589MJ
Eye diameter: 236 mm
Inside flange diameter: 190.5 mm
Mounting flange thickness: 5.6 mm
Max pad depth: D51
Number of vanes: 48
Air gap: 19.5 mm
Approx. disc weight: 6 kg
Face types available: G8/CG8
AP comments: Interchangeable
Select the correct side and face style from the available options.
Side
Face style
Pad depth
Approx. disc weight
SKU
Right
8 straight grooves (G8)
D51
6 kg
CP3581-564G8
Right
8 curved grooves (CG8)
D51
6 kg
CP3581-564CG8
Left
8 straight grooves (G8)
D51
6 kg
CP3581-565G8
Left
8 curved grooves (CG8)
D51
6 kg
CP3581-565CG8
Face style notes
G8: straight grooves, number is grooves per face.
CG8: curved grooves, number is grooves per face.
AP Racing part numbers: CP3581-564G8, CP3581-564CG8, CP3581-565G8, CP3581-565CG8.
