Not in stock, available to order
AP Racing Ventilated Brake Disc 295x25.4mm (CP3580-2894/2895)
Outside diameter: 295 mm
Thickness: 25.4 mm
Mounting PCD: 177.8 mm
Mounting holes: 12
Fixing type: Bolted
Mounting hole diameter: 6.4 mm
Eye diameter: 193 mm
Inside flange diameter: 164.3 mm
Mounting flange thickness: 5.8 mm
Max pad depth: D51
Number of vanes: 48
Air gap: 14 mm
Approx. disc weight: 4.3 kg
Face types available: G4/RD/P
Select the correct side and face style from the available options.
| Side | Face style | Pad depth | Approx. disc weight | SKU |
|---|---|---|---|---|
| Right | 4 straight grooves (G4) | D51 | 4.3 kg | CP3580-2894G4 |
| Left | 4 straight grooves (G4) | D51 | 4.3 kg | CP3580-2895G4 |
Face style notes
G4: straight grooves, number is grooves per face.
AP Racing part numbers: CP3580-2894G4, CP3580-2895G4.
Technical drawing: AP Racing customer drawing PDF.
Source: AP Racing 2025 Product Catalogue. Check the part number and mounting dimensions against your application.
For ordering assistance, email info@radaauto.ee.
