AP Racing Ventilated Brake Disc 270x22mm (CP2589-138)
Outside diameter: 270.0 mm
Thickness: 22.0 mm
Mounting PCD: 108.0 mm
Mounting holes: 4
Side: Symmetrical — fits either side.
| Side | Face style | Pad depth | Approx. disc weight | SKU |
|---|---|---|---|---|
| Symmetrical | 4 straight grooves (G4) | 52 mm | 4.8 kg | CP2589-138G4 |
| Symmetrical | 8 straight grooves (G8) | 52 mm | 4.8 kg | CP2589-138G8 |
Disc weights are reference values and can vary with the face machining. They exclude packaging.
Groove and drilling styles
G4: 4 straight, forward-facing grooves per face.
G8: 8 straight, forward-facing grooves per face.
AP Racing part numbers: CP2589-138G4, CP2589-138G8.
Check the part number and mounting dimensions against your application. See the AP Racing catalogue for full disc details.
