Xtreme Clutch 212 mm sprung organic single-plate clutch kit for the listed Honda S2000 manual applications.
FITMENT Honda S2000 2.0 VTEC AP1, from June 1999; F20C, 1997 cc petrol, 177 kW (supplier does not specify an end date). Honda S2000 2.0 VTEC, March 1999–October 2003; F20C1, 1997 cc petrol, 170 kW. Honda S2000 2.0 VTEC AP1, from October 2003; F20C3, 1997 cc petrol, 184 kW (supplier does not specify an end date). Honda S2000 2.2 VTEC AP2, from October 2003; F22C1, 2156 cc petrol, 176 kW (supplier does not specify an end date). Listed manual-transmission applications with the matching pull-type release arrangement only. Match the engine code, gearbox input spline, existing flywheel and release system. Not for other engines or gearbox conversions.
SPECIFICATIONS Part number: KHN21005-1A Construction: single plate Friction disc: sprung organic Disc diameter: 212 mm Input spline: 24 teeth, 26.2 mm diameter Flywheel step: −1.7 mm Release arrangement: pull type Recommended use: street performance
PURCHASED PARTS PACKAGE Heavy-duty pressure plate, sprung organic friction disc, pull-type release bearing, pilot bearing and alignment tool, as shown in the original supplier photograph. Flywheel and concentric slave cylinder (CSC) are not included.
INSTALLATION AND USE Follow the supplied kit-specific installation instructions and the manufacturer Honda S2000 clutch fitting bulletin TSB-262, including correct alignment and release-bearing engagement. Follow the supplied bedding-in instructions. Organic friction material is intended for progressive road engagement.
