HKS Hipermax S Coilovers Toyota C-Hr (NGX50) / Toyota C-Hr (ZYX10) 80330-AT048FD
1 839 €
/ per
Maksud sisalduvad hinnas.
Not in stock, available to order
Product description
80330-AT048FD
FITMENT Toyota C-Hr (NGX50) 2016-2023 Toyota C-Hr (ZYX10) 2016-2023
GENERAL FEATURES Series - S Toyota C-Hr (NGX50) - Engine - 8NR-FTS / Make to order item Vehicle data for 4WD model. Fixed Damping Force type. Toyota C-Hr (ZYX10) - Engine - 2ZR-FXE(2ZR-1NM) / Make to order item Data for 2WD, HYBRID model. Fixed Damping Force type.
FRONT FEATURES Toyota C-Hr (NGX50) - Spring rate N/mm (kgf/mm) - 39(4) Toyota C-Hr (NGX50) - Spring free height, mm - 220(Barrel) Toyota C-Hr (NGX50) - Damping force at 0.1 m/s, rebound/compression, N - 412/216 Toyota C-Hr (NGX50) - Vehicle height (highest - lowest), mm - -44(-3 - -83) Toyota C-Hr (ZYX10) - Spring rate N/mm (kgf/mm) - 39(4) Toyota C-Hr (ZYX10) - Spring free height, mm - 220(Barrel) Toyota C-Hr (ZYX10) - Damping force at 0.1 m/s, rebound/compression, N - 412/216 Toyota C-Hr (ZYX10) - Vehicle height (highest - lowest), mm - -32(0 - -71)
REAR FEATURES Toyota C-Hr (NGX50) - Spring rate N/mm (kgf/mm) - 49(5) Toyota C-Hr (NGX50) - Spring free height, mm - 250(Barrel) Toyota C-Hr (NGX50) - Damping force at 0.1 m/s, rebound/compression, N - 250/162 Toyota C-Hr (NGX50) - Vehicle height (highest - lowest), mm - -51(-3 - -77) Toyota C-Hr (ZYX10) - Spring rate N/mm (kgf/mm) - 49(5) Toyota C-Hr (ZYX10) - Spring free height, mm - 250(Barrel) Toyota C-Hr (ZYX10) - Damping force at 0.1 m/s, rebound/compression, N - 250/162 Toyota C-Hr (ZYX10) - Vehicle height (highest - lowest), mm - -39(0 - -59)
PURCHASED PARTS PACKAGE One HKS coilover set supplied under manufacturer part number 80330-AT048FD.
NOTES Follow the manufacturer installation instructions and the application notes above. Confirm supporting parts and any separately required components for the vehicle specification.
