HKS Hipermax S Coilovers Tesla Model 3 (3L13) 80330-AA001P

80330-AA001P

FITMENT
Tesla Model 3 (3L13) 2019-2023

GENERAL FEATURES
Series - S
Tesla Model 3 (3L13) - Engine - 3D5 / Make to order item Front Upper Mount Pillow ball type. Not compatible with 4WD trims.

FRONT FEATURES
Tesla Model 3 (3L13) - Spring rate N/mm (kgf/mm) - 78(8)
Tesla Model 3 (3L13) - Spring free height, mm - 250
Tesla Model 3 (3L13) - Damping force at 0.1 m/s, rebound/compression, N - 687/382
Tesla Model 3 (3L13) - Vehicle height (highest - lowest), mm - -28(1 - -75)

REAR FEATURES
Tesla Model 3 (3L13) - Spring rate N/mm (kgf/mm) - 88(9)
Tesla Model 3 (3L13) - Spring free height, mm - Special
Tesla Model 3 (3L13) - Damping force at 0.1 m/s, rebound/compression, N - 343/451
Tesla Model 3 (3L13) - Vehicle height (highest - lowest), mm - -24(0 - -73)

PURCHASED PARTS PACKAGE
One HKS coilover set under part number 80330-AA001P. See the application table for the supplied specification and separately required parts.

NOTES
Professional installation and the manufacturer application instructions are required. The image is a manufacturer product-family illustration. The supplied components and dimensions follow the part number and table above.

Manufacturer application chart
