HKS Hipermax S Coilovers Suzuki Swift (ZC71S) / Suzuki Swift (ZC21S) / Suzuki Swift (ZC11S) / Suzuki Swift Sport (ZC31S) 80330-AS002

80330-AS002

FITMENT
Suzuki Swift (ZC71S) 2007-2010
Suzuki Swift (ZC21S) 2004-2009
Suzuki Swift (ZC11S) 2004-2010
Suzuki Swift Sport (ZC31S) 2005-2010

GENERAL FEATURES
Series - S
Suzuki Swift (ZC71S) - Engine - K12B / Make to order item Height data is based on ZC31S.
Suzuki Swift (ZC21S) - Engine - M15A / Make to order item Height data is based on ZC31S.
Suzuki Swift (ZC11S) - Engine - M13A / Make to order item Height data is based on ZC31S.
Suzuki Swift Sport (ZC31S) - Engine - M16A / Make to order item

FRONT FEATURES
Suzuki Swift (ZC71S) - Spring rate N/mm (kgf/mm) - 69(7)
Suzuki Swift (ZC71S) - Spring free height, mm - 200
Suzuki Swift (ZC71S) - Damping force at 0.1 m/s, rebound/compression, N - 515/324
Suzuki Swift (ZC71S) - Vehicle height (highest - lowest), mm - 24(0 - -54)
Suzuki Swift (ZC21S) - Spring rate N/mm (kgf/mm) - 69(7)
Suzuki Swift (ZC21S) - Spring free height, mm - 200
Suzuki Swift (ZC21S) - Damping force at 0.1 m/s, rebound/compression, N - 515/324
Suzuki Swift (ZC21S) - Vehicle height (highest - lowest), mm - -24(0 - -54)
Suzuki Swift (ZC11S) - Spring rate N/mm (kgf/mm) - 69(7)
Suzuki Swift (ZC11S) - Spring free height, mm - 200
Suzuki Swift (ZC11S) - Damping force at 0.1 m/s, rebound/compression, N - 515/324
Suzuki Swift (ZC11S) - Vehicle height (highest - lowest), mm - -24(0 - -54)
Suzuki Swift Sport (ZC31S) - Spring rate N/mm (kgf/mm) - 69(7)
Suzuki Swift Sport (ZC31S) - Spring free height, mm - 200
Suzuki Swift Sport (ZC31S) - Damping force at 0.1 m/s, rebound/compression, N - 515/324
Suzuki Swift Sport (ZC31S) - Vehicle height (highest - lowest), mm - -24(0 - -54)

REAR FEATURES
Suzuki Swift (ZC71S) - Spring rate N/mm (kgf/mm) - 39(4)
Suzuki Swift (ZC71S) - Spring free height, mm - 170(Barrel)
Suzuki Swift (ZC71S) - Damping force at 0.1 m/s, rebound/compression, N - 235/147
Suzuki Swift (ZC71S) - Vehicle height (highest - lowest), mm - -32(0 - -60)
Suzuki Swift (ZC21S) - Spring rate N/mm (kgf/mm) - 39(4)
Suzuki Swift (ZC21S) - Spring free height, mm - 170(Barrel)
Suzuki Swift (ZC21S) - Damping force at 0.1 m/s, rebound/compression, N - 235/147
Suzuki Swift (ZC21S) - Vehicle height (highest - lowest), mm - -32(0 - -60)
Suzuki Swift (ZC11S) - Spring rate N/mm (kgf/mm) - 39(4)
Suzuki Swift (ZC11S) - Spring free height, mm - 170(Barrel)
Suzuki Swift (ZC11S) - Damping force at 0.1 m/s, rebound/compression, N - 235/147
Suzuki Swift (ZC11S) - Vehicle height (highest - lowest), mm - -32(0 - -60)
Suzuki Swift Sport (ZC31S) - Spring rate N/mm (kgf/mm) - 39(4)
Suzuki Swift Sport (ZC31S) - Spring free height, mm - 170(Barrel)
Suzuki Swift Sport (ZC31S) - Damping force at 0.1 m/s, rebound/compression, N - 235/147
Suzuki Swift Sport (ZC31S) - Vehicle height (highest - lowest), mm - -32(0 - -60)

PURCHASED PARTS PACKAGE
One HKS coilover set supplied under manufacturer part number 80330-AS002.

NOTES
Follow the manufacturer installation instructions and the application notes above. Confirm supporting parts and any separately required components for the vehicle specification.

Manufacturer product details.
