GENERAL FEATURES Series - S Honda Odyssey (RB3) - Engine - K24A / Make to order item 2WD Honda Odyssey (RB4) - Engine - K24A / Make to order item 4WD Honda Odyssey (RB1) - Engine - K24A / Make to order item 2WD Honda Odyssey (RB2) - Engine - K24A / Make to order item 4WD, ABSOLUTE
FRONT FEATURES Honda Odyssey (RB3) - Spring rate N/mm (kgf/mm) - 69(7) Honda Odyssey (RB3) - Spring free height, mm - 250(Barrel) Honda Odyssey (RB3) - Damping force at 0.1 m/s, rebound/compression, N - 981/255 Honda Odyssey (RB3) - Vehicle height (highest - lowest), mm - -32(0 - -76) Honda Odyssey (RB4) - Spring rate N/mm (kgf/mm) - 69(7) Honda Odyssey (RB4) - Spring free height, mm - 250(Barrel) Honda Odyssey (RB4) - Damping force at 0.1 m/s, rebound/compression, N - 981/255 Honda Odyssey (RB4) - Vehicle height (highest - lowest), mm - -26(-3 - -85) Honda Odyssey (RB1) - Spring rate N/mm (kgf/mm) - 69(7) Honda Odyssey (RB1) - Spring free height, mm - 250(Barrel) Honda Odyssey (RB1) - Damping force at 0.1 m/s, rebound/compression, N - 981/255 Honda Odyssey (RB1) - Vehicle height (highest - lowest), mm - -35(0 - -76) Honda Odyssey (RB2) - Spring rate N/mm (kgf/mm) - 69(7) Honda Odyssey (RB2) - Spring free height, mm - 250(Barrel) Honda Odyssey (RB2) - Damping force at 0.1 m/s, rebound/compression, N - 981/255 Honda Odyssey (RB2) - Vehicle height (highest - lowest), mm - -46(-18 - -91)
REAR FEATURES Honda Odyssey (RB3) - Spring rate N/mm (kgf/mm) - 118(12) Honda Odyssey (RB3) - Spring free height, mm - 200 Honda Odyssey (RB3) - Damping force at 0.1 m/s, rebound/compression, N - 902/290 Honda Odyssey (RB3) - Vehicle height (highest - lowest), mm - -41(0 - -66) Honda Odyssey (RB4) - Spring rate N/mm (kgf/mm) - 118(12) Honda Odyssey (RB4) - Spring free height, mm - 200 Honda Odyssey (RB4) - Damping force at 0.1 m/s, rebound/compression, N - 902/290 Honda Odyssey (RB4) - Vehicle height (highest - lowest), mm - -33(-16 - -69) Honda Odyssey (RB1) - Spring rate N/mm (kgf/mm) - 118(12) Honda Odyssey (RB1) - Spring free height, mm - 200 Honda Odyssey (RB1) - Damping force at 0.1 m/s, rebound/compression, N - 902/290 Honda Odyssey (RB1) - Vehicle height (highest - lowest), mm - -32(0 - -83) Honda Odyssey (RB2) - Spring rate N/mm (kgf/mm) - 118(12) Honda Odyssey (RB2) - Spring free height, mm - 200 Honda Odyssey (RB2) - Damping force at 0.1 m/s, rebound/compression, N - 902/290 Honda Odyssey (RB2) - Vehicle height (highest - lowest), mm - -43(-2 - -77)
PURCHASED PARTS PACKAGE One HKS coilover set supplied under manufacturer part number 80330-AH014.
NOTES Follow the manufacturer installation instructions and the application notes above. Confirm supporting parts and any separately required components for the vehicle specification.
