GENERAL FEATURES Series - S Honda Jade (FR4) - Engine - LEB-H1 / Make to order item Grade - HYBRID X, RS Honda Jade (FR5) - Engine - L15B / Make to order item Grade - HYBRID X, RS
FRONT FEATURES Honda Jade (FR4) - Spring rate N/mm (kgf/mm) - 39(4) Honda Jade (FR4) - Spring free height, mm - 250(Barrel) Honda Jade (FR4) - Damping force at 0.1 m/s, rebound/compression, N - 402/127 Honda Jade (FR4) - Vehicle height (highest - lowest), mm - -32(0 - -49) Honda Jade (FR5) - Spring rate N/mm (kgf/mm) - 39(4) Honda Jade (FR5) - Spring free height, mm - 250(Barrel) Honda Jade (FR5) - Damping force at 0.1 m/s, rebound/compression, N - 402/127 Honda Jade (FR5) - Vehicle height (highest - lowest), mm - -32(0 - -49)
REAR FEATURES Honda Jade (FR4) - Spring rate N/mm (kgf/mm) - 78(8) Honda Jade (FR4) - Spring free height, mm - Special Honda Jade (FR4) - Damping force at 0.1 m/s, rebound/compression, N - 441/177 Honda Jade (FR4) - Vehicle height (highest - lowest), mm - -41(0 - -60) ※5 Honda Jade (FR5) - Spring rate N/mm (kgf/mm) - 78(8) Honda Jade (FR5) - Spring free height, mm - Special Honda Jade (FR5) - Damping force at 0.1 m/s, rebound/compression, N - 441/177 Honda Jade (FR5) - Vehicle height (highest - lowest), mm - -41(0 - -60) ※5
PURCHASED PARTS PACKAGE One HKS coilover set supplied under manufacturer part number 80330-AH016.
NOTES Follow the manufacturer installation instructions and the application notes above. Confirm supporting parts and any separately required components for the vehicle specification.
