GENERAL FEATURES Series - S Honda Cr-Z (ZF2) - Engine - LEA-MF6 / Make to order item Developed with CR-Z 6MT Honda Cr-Z (ZF1) - Engine - LEA-MF6 / Make to order item Developed with CR-Z 6MT
FRONT FEATURES Honda Cr-Z (ZF2) - Spring rate N/mm (kgf/mm) - 59(6) Honda Cr-Z (ZF2) - Spring free height, mm - 200 Honda Cr-Z (ZF2) - Damping force at 0.1 m/s, rebound/compression, N - 412/343 Honda Cr-Z (ZF2) - Vehicle height (highest - lowest), mm - -30(0 - -82) Honda Cr-Z (ZF1) - Spring rate N/mm (kgf/mm) - 59(6) Honda Cr-Z (ZF1) - Spring free height, mm - 200 Honda Cr-Z (ZF1) - Damping force at 0.1 m/s, rebound/compression, N - 412/343 Honda Cr-Z (ZF1) - Vehicle height (highest - lowest), mm - -33(0 - -85)
REAR FEATURES Honda Cr-Z (ZF2) - Spring rate N/mm (kgf/mm) - 49(5) Honda Cr-Z (ZF2) - Spring free height, mm - 200(Barrel) Honda Cr-Z (ZF2) - Damping force at 0.1 m/s, rebound/compression, N - 275/206 Honda Cr-Z (ZF2) - Vehicle height (highest - lowest), mm - -35(-12 - -59) Honda Cr-Z (ZF1) - Spring rate N/mm (kgf/mm) - 49(5) Honda Cr-Z (ZF1) - Spring free height, mm - 200(Barrel) Honda Cr-Z (ZF1) - Damping force at 0.1 m/s, rebound/compression, N - 275/206 Honda Cr-Z (ZF1) - Vehicle height (highest - lowest), mm - -37(-14 - -61)
PURCHASED PARTS PACKAGE One HKS coilover set supplied under manufacturer part number 80330-AH002.
NOTES Follow the manufacturer installation instructions and the application notes above. Confirm supporting parts and any separately required components for the vehicle specification.
